Universal Frame System · S-05
Multi-tine Shaft
High-density fine-tine aeration
The Multi-tine Shaft applies the same patented vibration technology in a much tighter pattern: replaceable multi-tine shells put 55 holes into every square foot with a shallow, gentle action. With the optional seed box attachment it prepares ground for seed and meters a wide variety of cool- and warm-season grass seed — a perfect one-pass overseeder.
[ SPECIFICATION ]
Spec sheet
| Action | Fine-tine vibratory |
|---|---|
| Aeration density | 55 holes per sq ft |
| Vibration depth | 1⅜ in |
| Side-to-side tine travel | ½ in |
| Shells (6 per rotor) | 24 / 36 / 48 by frame |
| Shaft weight | 170–340 lb by frame |
| Best for | Overseeding · netted sod |
Specs as published by 1st Products; ranges span the UA40 / UA60 / UA80 frame widths. Verify final configuration with your dealer.
